1 / 3Swivel Lifting Points / VLBG
Designed to lift heavy loads, ranging from 0.75 to 15 tons, which need to be turned or flipped. With a maximum swivel range of 360° GR80+10 rings can support the entire load in all mounting positions.
APPLICATIONS
- Used in a wide variety of industrial lifting applications
- Ideal for machinery and various lifting & lashing applications
FEATURES
- 100% Magnaflux crack detection
- Rated at 100% at 90° angle
- 20,000 cycle fatigue rated to 1.5 times WLL
- Hoist ring bail are designed by forged alloy steel, quenched & tempered
- 360° degree swivel with 180 pivot function
From $122.10 ex. GST
Narrow it down
Pick your sizes
| Size | Price | Quote |
|---|---|---|
| M8 (0.3T)$122.10 | $122.10 | |
| M10 (0.63T)$128.70 | $128.70 | |
| M12 (1.0T)$145.20 | $145.20 | |
| M16 (1.5T)$162.80 | $162.80 | |
| M20 (2.5T)$176.00 | $176.00 | |
| M24 (4.0T)$200.20 | $200.20 |
Quotes are free and come back within one business day. Everything we supply is rated, tagged and certified to AS/NZS.
About this product
